- Four universal probes act as a combination transmitter and receiver (transceiver)
- Test multiple piles in one day (6 times more efficient than 2-channel systems)
- Collect 6 profiles with only one pull – common 4-tube shaft only one pull is needed to complete testing
-
-
- Thin, light, ergonomic design with a rugged cast aluminum case and large touchscreen
- More intuitive interface with multi-touch technology (The PDA-8G display responds to gesture controls like swiping, pinch-to-zoom, etc.)
- Up to 8 data acquisition channels in wired configuration or up to 16 data acquisition channels in wireless configuration
- All data acquisition channels are universal – any sensor type is compatible with any input channel. Ability to connect any combination of strain transducers and accelerometers to any channel (wired or wireless configuration)
- Smart PDA-8G sensors (the PDA-8G identifies the sensor type, serial number, and calibration factor)
- Unified operating system (same software program used on PDA unit and PC)
- Data may be collected at 120 blows per minute (BPM) making it easier to test piles being driven by hydraulic hammers with high blow rates
- Automated drive log
- Allows for multiple-level (LE) instrumentation
- Quick swap lithium-ion battery pack for easy change out and battery meter
- PDIPLOT software is integrated into PDA-S software
- Optional: Dynamic Load Tester (DLT) software add-on to streamline data collection and analysis of drilled foundations
- Optional: SPT Analyzer software add-on with integrated report generation
- Older gages can be used with PDA-8G through adapters
-
